HYBRID Coater Service Manual ver1.1 Appendix G
161
G. EL-04876 Dispense Head PCB Overview
This appendix shows more detailed information about the connectors on the outside of the
EL-04876 Dispense Head PCB. This PCB is only used in some HC-200 machines. See
Chapter 6 for information regarding these machines.
CONNECTOR PINNING
Below figure shows the pinning of the connectors which are the counterparts of the
connectors present on the PCB.
CONNECTOR NUMBERING
Below figure shows the position of the connectors on the PCB.
