Chapter 1 HYBRID Coater Service Manual ver1.1
4
1. Introduction
1.1 About this Manual
This manual provides information to be used by the DIMA authorized service engineer to
maintain and repair the HYBRID Coating machine. It describes the HYBRID C, it’s cabling
and pneumatics, regular maintenance work, and the spare parts. The manual further
describes how to perform some small repairs, and modifications. The options for the HYBRID
C are also described in this Service Manual.
For general information about the HYBRID C, refer to the user documentation (User Manual
+ Machine Reference Manual).
Due to technical innovations and improvements, data in this manual may differ from the
machine at hand. DIMA however tries to keep this manual as up to date as possible.
Next table shows an overview of the previous and current versions of this manual.
Version Release date Changes
1.0 October 2007 Initial Release
1.1 July 2008 Set-up of Chapter 5 changed, also added
checklist. In Chapter 9 the Section about
stepper motors SS53 was extended . Also the
revision of the stop pin was added. Additional
SS-numbers were given in Chapter 10. Valve
heating added in several Chapters.
When you have any questions or remarks about the HYBRID Conformal Coating machine or
this Service Manual, please contact DIMA.
DIMA Group B.V.
Beukelsdijk 2
5753 PA Deurne
Tel : +31 493 352 752
Fax: +31 493 352 750
e-mail: service@dimagrp.com
