HYBRID Coater Service Manual ver1.1 Appendix F
155
F. EL-04875 Connection PCB Overview
This appendix shows more detailed information about the connectors on the outside of the
EL-04875 Connection PCB.
NOTE: there a two versions with the same part number. The newest version is upwards
compatible, which means that the new version can be used instead of the old version and
only has additional possibilities.
CONNECTOR PINNING
Below figure shows the pinning of the connectors which are the counterparts of the
connectors present on the PCB.
