DIMA HC-200 - 6 Electrical Wiring; Electrical Wiring Diagrams; Overview of the Wiring Diagrams

Chapter 6 HYBRID Coater Service Manual ver1.1
50
6. Electrical Wiring
6.1 Electrical Wiring Diagrams
At this moment there are 2 revisions of the Electrical Wiring Diagram. The serial number of
the machine determines which revision is valid.
Appendix A shows the wiring diagrams of the electro panel with Revision 1.0. Other wiring
diagrams match with Revision 1.1.
Appendix B shows the wiring diagrams with Revision 1.1.
 Serial numbers HC-100  Revision  Connection
PCB
 Dispense Head
PCB
 600200700001  1.0  EL-04875  none
 600200700002  1.0  EL-04875  none
 ≥600200700003  1.1  EL-04875  EL-04879
 Serial numbers HC-200  Revision  Connection
PCB
 Dispense Head
PCB
 601200600002 till
601200600005
 1.0  EL-04875  EL-04876
 601200700001  1.1  EL-04875  EL-04876
 ≥601200700002  1.1  EL-04875  EL-04806
Most changes at Revision 1.1 are made on the electro panel:
 The voltage used for the control circuit (on, off and emergency stop button) is
changed from 230VAC to 24VAC.
 Numbers of connectors on the electro panel are changed.
6.2 Overview of the Wiring Diagrams
The HYBRID-C exists of several modules. Each have their own wiring circuit diagram. The
drawing numbers have the following pattern:
MHC-0200-yyzz
 yy : running number
 zz : module number
