HYBRID Coater Service Manual ver1.1 Chapter 5
47
Actions to be performed Frequency
per two
years
Done
11 Draining EP Differential Pressure Switch 2
Remarks:
12 Check exhaust system 4
Remarks:
13 Lubrication of X and Y drive bearing nipples on runners 4
Remarks:
14 Lubrication of X and Y drive bearing spindles 4
Remarks:
15 Lubrication of Y guide bearing nipples on runners 2
Remarks:
16 Lubrication of Z/Ø drive bearing 2
Remarks:
17 Lubrication of Z drive bearing nipples on runners 4
Remarks:
18 Lubrication of Z drive bearing spindle 4
Remarks:
19 Lubrication of toothed belt Z movement 2
Remarks:
20 Check encoder on Ø axis 2
Remarks:
21 Check sensor on Z axis 2
Remarks:
22 Conveyor: product clamping and conveyor action 2
Remarks:
