Chapter 8 HYBRID Coater Service Manual ver1.1
60
LED Used for State
Off = Coil of door lock front not activated (FREE).
D57 Output door lock back LOCK On = Coil of door lock rear activated (LOCK).
Off = Coil of door lock rear not activated (FREE).
D58 Input CLOSED of door lock front On = Door lock front closed.
Off = Door lock front not closed.
D59 Input LOCKED of door lock front On = Door lock front locked.
Off = Door lock front not locked.
D60 Input CLOSED of door lock rear On = Door lock rear closed.
Off = Door lock rear not closed.
D61 Input LOCKED of door lock rear On = Door lock rear locked.
Off = Door lock rear not locked.
D62 Output light tower ‘RED’ On = Red light of light tower is on.
Off = Red light of light tower is off.
D63 Output light tower ‘ORANGE’ On = Orange light of light tower is on.
Off = Orange light of light tower is off.
D64 Output light tower ‘GREEN’ On = Green light of light tower is on.
Off = Green light of light tower is off.
D65 Output light tower ‘BLUE’ On = Blue light of light tower is on.
Off = Blue light of light tower is off.
Output is not used at this moment.
D66 Output light tower ‘WHITE’ On = White light of light tower is on.
Off = White light of light tower is off.
Output is not used at this moment.
D67 24Volt indication for product
sensor 1
On = 24Volt present on power supply of product
sensor 1. Off = 24Volt not present on power supply
of product sensor 1.
Output is only used when conveyor is present.
D68 24Volt indication for product
sensor 2
On = 24Volt present on power supply of product
sensor 2. Off = 24Volt not present on power supply
of product sensor 2.
Output is not used at this moment.
D69 PNP input for product sensor 1 On = Product sensor 1 detects a product.
Off = Product sensor 1 doesn’t detect a product.
Output is only used when conveyor is present.
D70 NPN input for product sensor 1 On = Product sensor 1 detects a product.
Off = Product sensor 1 doesn’t detect a product.
Input not used at this moment.
D71 PNP input for product sensor 2 On = Product sensor 2 detects a product.
Off = Product sensor 2 doesn’t detect a product.
