HYBRID Coater Service Manual ver1.1 Chapter 10

PN-2104 Pneumatic valve mounting screw for

use with PN-5024

PN-5015 Valve 5/2 (wide type used at older

version)

PN-5024 Valve for moving Z slide

PN-5032 Valve 5/2 (wide version with extra

thread for old units)
