21ECY-303 Preloaded Applications

ID Units Valid Range Default Value

Analog Value 30 Degrees-Celsius (°C) 4,5 to 25°C 13°C

EquipEnableDelay (AV31)

This variable is used to configure the delay before enabling the outputs after the fan status have been

proven.

ID Units Valid Range Default Value

Analog Value 31 Seconds N/A 30s

MinDamperPos (AV32)

This variable is used to configure the minimum dampers position when the system is in occupied

mode or standby mode. The dampers will be set to this position in standby mode only if the variable

EnableMinPosStby(BV15) is set to true.

ID Units Valid Range Default Value

Analog Value 32 Percent (%) 0 to 100% 15%

MinDamperCO2 (AV33)

This variable is used to configure the minimum dampers position when the system is equipped with ei-

ther a space or return CO2 sensor. The dampers will be set to this position in standby mode only if the

variable EnableMinPosStby(BV15) is set to true and they will modulate between this value and Min-

DamperPos(AV32) on a CO2 detection.

ID Units Valid Range Default Value

Analog Value 33 Percent (%) 0% to AV32 5%

FanStartDelay (AV34)

This variable is used to configure the delay before allowing the fan after the system have been set to

occupied.

ID Units Valid Range Default Value

Analog Value 34 Seconds N/A 30s

FanStopDelay (AV35)

This variable is used to configure the delay before stopping the fan. This delay is used to dissipate the

heat from the electric heater.

ID Units Valid Range Default Value

Analog Value 35 Seconds N/A 120s

ActCoolSp (AV36)

This variable is used to display the actual cooling setpoint used by the control algorithm. This value is

based on the occupancy status (MSV15) and the cooling setpoints(AV38 to AV40)

ID Units Valid Range Default Value

Analog Value 36 Degrees-Celsius (°C) N/A N/A

ActHeatSp (AV37)

This variable is used to display the actual heating setpoint used by the control algorithm. This value is

based on the occupancy status (MSV15) and the heating setpoints(AV41 to AV43)

Variables

Distech Controls ECLYPSE ECY-303 User Manual
