Running Diagnostics
4-22 72A-1230 Rev. F
July 22, 2005
The first six of these tests are applicable to the M4100; the last one is not. Use
of the Communications Loopback Test is described in ”Communications
Loopback Test” on page 4-40.
Follow these recommendations in deciding when to run each test:
* When contacting Doble by telephone or e-mail
(customerservice@doble.com), it will be helpful to have the results from these
two tests, including the contents of the Calver.log file, located in the DTA
directory.
Diagnostic Test Run the test when suggested by a
displayed message, when indicated in a
troubleshooting flow chart or table, or:
System Status * Run this test if you are experiencing any
malfunction or error.
Calibration Verification* 1. Run this test periodically to run a mock
specimen measurement, which checks
all system connections, including high
and low voltage cables.
2. Run this test after replacing a
component or otherwise repairing the
M4100.
Field Recalibration Run to calibrate the test set when one of the
calibration verification tests results in a Fail
or Re-cal rating.
Subsystem Diagnostics Run this test to exercise specific M4100
components.
M4100 Component List Run this test to obtain a list of recognized
M4100 components and their revision
numbers.
Thermal Profile Run this test if the M4100 appears to be
overheating or if an over-temperature
indication appears.
Communication Loopback
Test
Run to check communications between the
M4200c Controller (or laptop) and the
M4100 Instrument.
