Clipboard Configuration
2-14 72A-1230 Rev. F
July 22, 2005
Ramp Mode - Auto Ramp Mode raises the voltage automatically at a rate
selected separately in the Clipboard Configuration and DTA Configuration.
Manual Set Voltage allows raising the voltage by pressing the PGUP key to
raise the voltage rapidly, the PGDN key to lower the voltage rapidly, the up
arrow key to raise the voltage slowly, and the down arrow key to lower the
voltage slowly. The rates at which the voltages are raised and lowered
manually are selected separately in the Clipboard configuration and the DTA
Configuration.
Line Frequency - Select the frequency that corresponds to the user's system;
or, if trying to duplicate a test result made at another frequency, select either
frequency. Under normal system conditions, make the ± 5% selection. If your
power line frequency is itself experiencing this degree of variation, you may
be required to make the ± 10%
selection to avoid the effect of electrostatic
interference. The M4000 users Line Frequency Modulation to measure above
and below power line frequency to avoid measurement of electrostatic
interference.
M4000 Data Directory - This is the directory in which the Clipboard data is
to be stored. To change the default settings, use the mouse to click into the
M4000 Data Directory field. Then, edit the settings to reflect in which
directory the Clipboard data is stored.
Select a directory other than C:\DOBLE\DTA for data storage for both
Clipboard data and DTA data.* Click on the OK button to accept your
changes.
* For example, use C:\Doble\DTA\DATA.
Company: If filled in, this line will cause all tests to use the information in the
“Company” field when starting a new clipboard test.
Clipboard Configuration
When selecting the Clipboard tab, the following appears:
