Troubleshooting Resources
4-2 72A-1230 Rev. F
July 22, 2005
NOTE A majority of test set problems involve only the test leads, i.e. the High
Voltage Test Cable and the Low Voltage Test Leads. Be especially alert to
the condition of these items. They can be readily tested by following the
procedures in ”Running Other Tests” on page 4-42.
Troubleshooting Resources
The operator should consult this chapter first when a problem appears. It will
help isolate the problem to the M4200c or the M4100 and will point to the
most appropriate resources available to resolve the problem as quickly as
possible. There are four categories of resources available, and these are
summarized in Table 4.2.
Table 4.1 Quick Checks: Can You Answer Yes To These Items:
Item
The communications cable is securely connected between the
M4200c (or third-party controller) and the M4100.
Both the M4200c and M4100 are turned on and connected to an
active, stable power source, appropriately rated and grounded.
Both safety switches were held closed during a specimen test and
released between tests as required.
The test cables are securely connected to the specimen under test,
and the specimen is ungrounded.
All the test leads are in good condition.
The printer is correctly loaded with paper of the proper kind.
Neither unit has been dropped recently or otherwise undergone
rough treatment.
The floppy disk drive was empty during M4000 software boot-up.
The Num Lock and Caps Lock keys on the keyboard are switched
off.
