72A-1230 Rev. F 2-1
July 22, 2005
2. M4000 Software
Upgrading or Installing M4000 Software
Your M4200c Controller comes with all necessary software pre-installed. This
consists of the Windows XP operating system, the M4000 program, and for
users of the Doble Test Assistant, the optional DTA program. You may also
request the optional Leakage Reactance Test or External Reference Test
software. You may need to install this software if you are loading it onto an
office computer or laptop, upgrading from a previous version, or reinstalling
it. This chapter covers the following subjects:
• Installing M4000 software on your PC.
• Introduction to M4000 Software/Icon Descriptions/Configuration
Settings (see page 2-6)
Software Installation
WARNING Before starting, BACK-UP YOUR TEST DATA
NOTE If you have customized limit files, location.txt, and division.txt files from
DTA, save them separately, so you can transfer the data to the new version.
M4000 Software
NOTE The first time a test is run with newly installed software, the M4200c
Controller or your laptop computer being used as a Controller must
update the M4100 Instrument firmware. The user is notified of this
process by the message, “Downloading firmware to the M4100
Instrument – Please wait”. Do not interrupt this process. Otherwise, the
previous version of the software must be reloaded onto the M4200c or
your laptop, then the new version installed once again.
This section contains the steps to follow to install the M4000 software.
