M4000 Insulation Analyzer User Guide
72A-1230 Rev. F 4-53
July 22, 2005
W8/W9/W11 Cable Checkout
Check and reseat the W8, W9 and W11 cable connectors, which are identified
in Figure 4.26.
Figure 4.26 Card Cage
W11 Connector
W9 Connector
W8 Connector
