M4000 Insulation Analyzer User Guide
72A-1230 Rev. F 2-7
July 22, 2005
Leakage Reactance 10. One Leakage Reactance file can now contain all tests in a series: Three
Phase Equivalent, Per Phase, and tests on different taps. Data entry is now
more intuitive.
External Reference 11. On the External Reference form, both UST and GST tests can be stored all
on the same form.
12. You may now store reversal readings on the same line and automatically
average the results.
13. You may now store test circuit loss associated with the GST test, and the
program will automatically subtract the loss from the test results.
The M4000 Program
To start the M4000 Software: turn on the M4200c Controller; or, if using your
laptop, and the program executable is not in your “StartUp” group:
1. Select All Programs from the Windows Start button menu.
2. Select the Doble Program Group.
3. Select the M4000 icon.
4. Click the OK button on the “About The M4000 Software” window. You
are now at the M4000 clipboard screen. The menu bar contains a number
of choices, with a row of short-cut icons just below.
Icons
Before step 4 above, the basic icons shown and their functions are described as
follows:
Icon Description
Open M4000 data file. New M4000 files have the extension
.m4k, but old M4000 files can also be opened using this
command.
Exit the M4000 Software, or select Exit from the File pull
down menu.
