Shipping Instructions
1-18 72A-1230 Rev. F
July 22, 2005
Shipping Instructions
M4000 Test Set Always ship the M4000 and M4200c in separate
containers.
Ship in special packing cases provided by Doble or
pack in cases with at least 4" of Styrofoam-type
padding on all sides. The HV cable pothead-guide
receptacle on the M4100 Instrument should be covered
to keep out foreign material.
On package, write: FRAGILE – PLEASE DO NOT
DROP
Accessory Case Pack leads, cables, and accessories in the cable bag
furnished with the set.
Liquid-Insulation Cell The Cell and Plastic Carrying Case must be thoroughly
cleaned to prevent accidental contamination of the
Accessory Case and the environment. If the Accessory
Case is either not shipped or is too full, then the clean
Cell and Carrying Case should be shipped in a separate
padded cardboard box, or better. Padding should be
installed inside and around the Cell.
On package, write: FRAGILE – PLEASE DO NOT
DROP
NOTE When shipped by commercial carrier, the M4100, M4200c and
Accessories should be properly padded and packed as specified above.
Suitably padded shipping containers for temporary use or purchase are
available from Doble upon request.
Ship to:
Doble Engineering Company
85 Walnut Street
Watertown, Massachusetts 02472-4037
USA
NOTE Test sets that are transported appreciable distances should be checked
upon arrival. This includes sets that have been shipped from the Doble
Engineering Company. The test set and its accessories should be
examined upon receipt for signs of physical damage. The simplest and
most effective method for checking overall performance of the M4000 is
to use the Doble Liquid Insulation Cell as described in ”Checking
Instrument Accuracy in the Field” on page 4-43.
