doble M4200c User Manual

Avoiding Problems
4-4 72A-1230 Rev. F
July 22, 2005
Avoiding Problems
The M4000 test set is rugged and can give many years of trouble-free service
if it is handled with reasonable care. The following practices are suggested to
minimize performance problems in the field.
Precautions It is recommended that the following precautions be followed:
• Keep the M4100 Instrument and Accessories clean and dry. Select a
suitable storage location.
Table 4.3 Isolating the Problem
Observation Suggested Action
A numbered error message
appears in the display.
The M4100 is likely to be at fault. See
”Troubleshooting from Error Messages”
on page 4-16. Also, click on Help for
further guidance.
An un-numbered error
message appears in the
display.
The M4200c is likely to be at fault. See
”Troubleshooting from Diagnostics”
on page 4-21. Also, click on Help for
further guidance.
The M4000 fails to
complete the test of a
specimen or yields unusual
results.
The M4100 is likely to be at fault. See
”Troubleshooting from Symptoms”
on page 4-12.
The M4000 does not print as
expected.
The problem lies with the M4200c. See the
M4200c Controller manual.
A Diagnostics test has
failed.
If the Communications Loopback Test has
failed, the fault lies with the M4200c; see
”Communications Loopback Test”
on page 4-40. If any other Diagnostics test
has failed, the M4100 is probably at fault;
see ”Running Other Tests” on page 4-42.
Either the display or
keyboard is nonresponsive
or responds in an
unexpected manner.
The M4200c is at fault. See the M4200c
Controller manual.
The M4000 software is
either not working or acting
erratically.
The fault probably lies with the M4200c.
See the M4200c Controller manual.
Any other symptom, not
described above, is evident.
See ”Troubleshooting from Symptoms”
on page 4-12.
