M4000 Insulation Analyzer User Guide
72A-1230 Rev. F 1-13
July 22, 2005
Testing Mode
When assembled in the Testing Mode, the M4300 Transport serves as the field
desk for the M4000 Insulation Analyzer. The Testing Mode (Figure 1.10) was
designed to take advantage of the M4100 instrument's concentrated cluster of
connections, providing the user with a comprehensible testing setup and a
user-friendly environment while testing.
Figure 1.10 M4000 in Testing Mode
M4200c Controller
Intercase
Communication
Cable
High
Volta ge
Cable
Transporter
Safety
Ground
Diagnostic Test
Adapter Cable
120/240 V
Power Cable
Red Low
Voltage Cable
Safety Strobe
Remote Temperature
Humidity Sensor
Loopback Test
Connectors
Blue Low
Voltage Cable
Safety Switch 1&2
Controller Support
Frame
M4151 Calibration
Reference
