Storage and Moving Mode
1-12 72A-1230 Rev. F
July 22, 2005
3. Position the closed M4200c Controller upside down into the area with the
projections of the top cover of the M4100 Instrument. Buckle and tighten
the strap snugly around both the M4100 Instrument and the M4200c
Controller.
4. Lift the M4300 Transport into the upright position.
5. Place the Documentation Bag and Cable Carry Bag on top of the M4100
Instrument top cover. Buckle and tighten the strap to secure.
6. Place the Oil Test Cell on the brackets provided between the wheels on the
rear of the M4300 Transport, and secure it with the strap provided.
7. Place the High Voltage Cable into the brackets provided on the top, rear
part of the M4300 Transport and secure it with the strap provided.
8. Place the M4200c Controller Support frame into the tubes provided so that
the end faces forward.
NOTE The M4200c Controller Support frame should not be used for lifting the
M4300 Transport.
The M4000 Insulation Analyzer is now in Storage and Moving Mode.
