Menu Bar
2-10 72A-1230 Rev. F
July 22, 2005
Enter the DTA Field System program. This can also be done
by selecting DTA from the Mode pull-down menu item.
Click to open a Clipboard screen, where tests may be run and
recorded.
Click to enter External Reference/Source Mode, or select
External Reference/ Source from the Mode pull-down menu.
Click to enter Leakage Reactance Test Mode, or select
Leakage Reactance Test from the Mode pull-down menu.
Run a single test. This can also be done by selecting Run A
Single Test from the Test pull-down menu item, or by
pressing F2.
Run a multiple test. This can also be done by selecting Run A
Multiple Test from the Test pull-down menu item, or pressing
FN+F11.
Enter a note. When clicking on this icon, the software will ask
you which line the note corresponds to. The default is for line.
This can also be done by selecting Edit Test Note from the
Edit pull-down menu item.
View the air temperature and percent humidity associated
with each line of test data. This can also be done by selecting
Display Temp./Humidity from the Edit pull-down menu item.
Allows user to activate automatic temperature correction
function for the clipboard test mode.
Graph the selected clipboard results
Icon Description
