SECTION 1 General Information
0855855eng 6/08 1–3
2 Specifications
Weight: Print station (not including umbilical lines)
Model 5200: Approx. 63kg (140 lb)
Model 5400: Approx. 77kg (170 lb)
Printhead: Approx. 2.1kg (4.6 lb)
Dimensions: See Dimensional Drawing (Paragraph 3.0)
Noise Emission: Does not exceed 75 dB(A)
Electrical Standards: CE marked
ETL listed, conforms to ANSI/UL 60950 and
Canada/CSA 60950
Voltage Options: Model 5200: 1450W maximum,
115/200/208/230V, 50–60Hz, single phase
Model 5400: 2530W maximum,
200/208/230V, 50–60Hz, single phase
Environmental: Temperature range
Standard 5200/5400: 0°–40°C (32°–104°F)
Stainless 5200/5400: 0°–25°C (32°–77°F)
Relative humidity
<90%, non-condensing
IP Protection
Enclosure: IP45 (with doors latched)
Printhead: Not rated
Carton Sensor: IP65
Encoder: IP65
Print Area: 65mm x 1200mm (2.56" x 47")
Print Speed: 55m/min. (180 ft./min.) at Density 2
(recommended)
Warm-up Time: 60 minutes
Interface: RS232 serial port
RS422 serial port
RS485 serial port
Ethernet 10T/100T
Print Resolution: 100 DPI Vertical
150 DPI Horizontal
Bar Code Type: Code 39, EAN 128, Interleaved 2 of 5
UPC-A, EAN 13, 2D Bar Code
0855855eng 4/09
