SECTION 1 General Information
0855855eng 6/08 1–13
6 Removal from Service
Follow these instructions to remove the coder from service. These
instructions also pertain to transporting or storing the coder.
1. Use the Shutdown menu to cool down and power off the coder.
NOTE: Before moving the printhead, wait approximately two
hours for the printhead to cool and the “Shut down” message to
appear.
2. Disconnect the AC power cord from the electrical source.
3. Disconnect cables and connections, accessed from the I/O
door.
4. Disconnect the umbilical lines from the printhead and the
enclosure.
5. Remove the signal tower, carton sensor, and encoder, if
applicable.
6. Remove each printhead from its mounting assembly.
7. Package the enclosure, printhead(s), and cables in the original
shipping container.
