SECTION 4 Diagnostic Tools
4–2 0855855eng 6/08
STATUS LED (green)
Off Power is off
On Online
Blinking Warming up or cooling down (fast blinking) or
printhead is ready but offline (slow blinking)
INK LED (blue)
Off Ink level is okay
On Add ink
Blinking Add ink immediately
NOTE: After adding ink, it might be necessary to
press the ENTER key to resume printing.
FAULT LED (amber)
Off No present faults
On Warning
Blinking Error
If the coder detects a warning condition, a warning message will
appear on the display, but the coder will continue printing. If the
coder detects an error condition, printing will typically stop.
1.3 Signal Tower Lights
If your coder is equipped with the optional signal tower, the lights on
the signal tower correspond to the LED indicators on the user
interface module as follows:
GREEN The top lamp STATUS LED
BLUE The middle lamp INK LED
AMBER The bottom lamp FAULT LED
