SECTION 6 Field Replaceable Parts
6–26 0855855eng 6/08
11.4 Replacement
1. Reverse the steps in Removal, paragraph 10.3, to install the
new printhead volt board.
11.5 Final Steps
When paragraphs 10.2 through 10.4 are complete:
1. Install the front cover.
NOTE: The ground wire may need to be connected to the print
station first.
2. Connect the power cable and power on the Model 5200/5400.
