SECTION 4 Diagnostic Tools
0855855eng 6/08 4–19
2.5.16 Filter Usage Count
Access Level: Read–3
The Filter Usage Count parameter indicates the number of ink pump
strokes between the upper and lower ILS, which on a new filter will
take approximately 400 strokes. When the number is too large, the
system will generate a printhead supply warning and will
recommend replacing the filter.
The number of strokes increases as the filter becomes clogged.
As the filter loads up this number would increase until a warning is
given.
2.6 Print Station
The Print Station menu is used to monitor functioning and diagnose
problems with the print station.
2.6.1 Ink Door Switch
Parameter Options: Door Open, Door Closed
Access Level: Read–3
The Ink Door Switch parameter indicates whether the ink load door
is open or closed.
2.6.2 Ink Door Solenoid
Parameter Options: Locked, Unlocked
Access Level: Read–3; Toggle–3
The Ink Door Solenoid parameter displays the status of the door
solenoid, which locks and unlocks the ink load door.
2.6.3 Line Voltage
Access Level: Read–3
The Line Voltage parameter indicates the percentage of power for
the configured line voltage.
