Trends/data dialogs
162 Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n
Overview
The Trends/Data dialog provides numerous trend,
data review, and report pages.
To access Trends/Data dialog
1 Select the Trends/ Data... button on the main
menu bar.
2 Select one of the following tabs to access the
desired page:
– Trends – accesses the graphical and
tabular trends and associated functions.
– ECG – displays all connected ECG leads
(see page 215) and ST complexes (see
page 229).
– Ventilator – displays respiratory/ventilation
loops (see page 437). When a Perseus
A500 is connected, the name of this tab
changes to Anesthesia/ Ventilation to
display anesthesia/ventilation parameters.
– Hemo – accesses the hemodynamic
calculations and results data (see
page 177).
– Labs – accesses the laboratory results (see
page 177).
– Reports – accesses the tabs for configuring
and requesting reports (see “Printing
reports“on page 498).
Trending behavior
The Cockpit stores up to 96 hours of continuous
and discrete trend values. Trend data are sampled
every 30 seconds at the Cockpit where the trend
display is updated automatically. Trend updates at
the Cockpit are reflected on connected network
devices every 60 seconds.
Trend data can be viewed in graphical or tabular
format. Additional customization of the trend
display includes:
– selecting which parameters are displayed
– selecting the time period of the trended
parameters.
The Cockpit maintains one trend database per
patient. If the user docks an M540 that was
previously docked on another Cockpit, the trend
data from the previous Cockpit are transferred over
the network to the new Cockpit, provided a patient
ID was entered.
If the user undocks an M540, trending is
suspended on the Cockpit but the trend data
remain intact. When he user redocks the M540, any
new trend data collected during patient transport
are transferred to the Cockpit. Transferring the
trend data may take a brief moment during which
time trends are not accessible.
Refer to the instructions for use Infinity Acute Care
System – Infinity M540 for a detailed description of
the M540 trend functions.
Supported parameters
A trended parameter can either be represented in
tabular or graphical form. The following sections
explain how the different parameter groups are
plotted on the graphical trends.
NOTE
After docking/undocking the M540, one minute of
trend data collected during this transition period
may not be displayed at the ICS equipped with
software version VG1. However, these trends are
visible at the Cockpit.
