Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 415
External devices – MEDIBUS.X devices
Paw setup functions
See page 414 for information on how to access this
page.
Ventilator parameter setup functions
See page 414 for information on how to access this
page.
Selection Available settings Description
Paw scale 10, 15, 20, 25 (default), 30, 40, 50, 60, 70, 80,
100, 120 mbar
Determines the scale of the
displayed Paw waveform.
Parameter 1 PEEP, PIP (default), Pmean, Pplat Selects the primary
parameter in the Paw
parameter field.
Parameter 2 PEEP, PIP, Pmean (default), Pplat Selects the second
parameter in the Paw
parameter field.
Parameter 3 PEEP (default), PIP, Pmean, Pplat Selects the third parameter
in the Paw parameter field.
Color Red, green, blue, yellow, light blue (default),
purple, orange, white.
Determines the color of all
MEDIBUS.X parameter
fields, waveforms, and
loops.
Selection Available settings Description
Flow scale 5, 10, 15, 20 (default in neonatal mode),
35, 50, 100 (default in adult and pediatric
mode), 150, 200 L/min
Determines the scale of the
displayed Flow waveform.
Vol scale 5, 10, 25, 50 (default in neonatal mode),
75, 100, 250, 500, 1000 (default in
pediatric and adult mode), 1500 mL
Determines the scale of the
displayed Volume waveform.
