Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 589
Technical data
Infinity P2500
Physical specifications
Dimensions (W x D x H) 218 mm x 150 mm x 348 mm (8.6 in x 5.9 in x 13.7 in)
Weight 10 kg (22 lbs)
Cooling Natural convection (no cooling fan)
Connections – Nurse call
– System cable (quantity of 2)
– Ethernet (quantity of 2)
– RS232 (modular jack)
– Potential equalization connector (optional)
Environmental specifications
Humidity (non-condensing) Operating: 20% to 95%
Storage/Transport: 5% to 95%
Temperature Operating: 0 °C to 40 °C (0 °F to 104 °F)
Storage: –20 °C to 60 °C (–4 °F to 140 °F)
Ambient pressure Operating: 647 hPa to 1060 hPa
Storage: 500 hPa to 1060 hPa
Protection against ingress of water IPX1 according to IEC 60529 – protected against harmful
effects of dripping water when mounted vertically with the
connectors facing down
Electrical specifications
Input voltage 100 to 240 V AC (50 to 60 Hz)
Input current 4 A
Mode of operation Continuous
Batteries Rechargeable lead acid batteries
Operating time: approximately 5 minutes @ 250 W
Recharging time: maximum 12 hours
DC output – 250 W (TOTAL of two system cable output)
– +28 V DC (when powered by AC mains power supply)
– +24 V DC (when powered by fully charged batteries)
– SELV according to IEC60601-1.
