6
Chapter 1 Before Operation
Copyright © 2018 Duplo Corporation All Rights Reserved
Storage of guide plate unit/cross folding lever
1
Open the top cover.
Open or close the top cover
gently.
Hands or ngers may be caught in the
cover section. Doing so may result in
injury.
2
3
2
Store the guide plate unit on the
magnet in the figure at right.
3
Store the cross folding lever at the
position in the figure at right.
Insert the cross folding lever into the storage
pillar.
After use, always be sure to insert the
cross folding lever boss hole into the pillar.
Motion during an action is dangerous. In
addition, there is a risk of entanglement in
the roller, causing damage to the machine.
CarefullystoretheL-shapedhexwrenchtogetherwiththeInstructionManual.
2-4. Connecting power cord
Otherwise electric hazards may occur.
Do not touch the power plug with wet hands.
1
Install the power cord to the machine.
2
Connect the power plug to the outlet.
To Next Page
