3. Standard Folding of Non-Standard Size Paper
Do not put fingers inside during operation.
Keep away long hair, ties, jewelry and loose clothing.
It could cause injury.
Paper
feed
direction
Length: 182 to 432 mm/
7.17 to 17.00 inches
Width:
128 to 297 mm/
5.04 to 11.69 inches
Paper
Non-standardsizepaperreferstopapersizesother
thanthestandardsizepaper(6types).
Theprocessablepapersizesareasfollows.
Maximum:297x432mm/
(WxL)   11.69x17.00inches
Minimum:128x182mm/
(WxL)   5.04x7.17inches
Forsinglefolding,theprocessableminimumpapersizeisasfollows.
Minimum(WxL):90x128mm/3.54x5.04inches
Theoperatingprocedureisdescribedwithlength300mm/11.81inchespapersubjectedto"letterfolding"as
the example.
1
Measure the paper length.
2
Stack paper in the paper feed tray.
Chapter 2 “2-3. Stacking paper” (p.19)
3
Set the paper size and folding mode.
DF-850
Rough adjustment knob set position table
L = Paper length
Single fold Double fold Irregular
accordion
fold
Letter fold Accordion
fold
Gate fold
Folding plate 1 L/2 L/2 3L/4 L/3 2L/3 L/4
Folding plate 2 At the
highest point
L/4 L/4 L/3 L/3 L/2
