Chapter3AdvancedOperation

2-3. Aligning stacker roller position

Stacker roller positioning table

Standard paper Single fold Double

fold

Irregular

accordion

fold

Letter fold Accordion

fold

Gate fold

For EU A3 2 6 2 4 4 2

B4 2 6 3 5 5 3

A4 4 6 4 6 6 4

B5 5 6 4 6 6 5

A5 5 6 5 6 6 5

B6 6 6 6 6 6 6

ForNA LGR 1 5 1 4 4 2

LGL 2 6 3 5 5 3

LTR 4 6 4 6 6 4

IN/ST 5 6 5 6 6 5

Finished size (mm/inch) Stacker roller positioning

199to216/7.83to8.50 1

182to199/7.17to7.83 2

148.5to182/5.82to7.17 3

128to148.5/5.04to5.83 4

105to128.5/4.13to5.05 5

45.5to105/1.77to4.13 6

Thistableisthemeasureforuse.Fineadjustmentofthestackerrollerposition,basedontheusage

environment(temperature,humidity),paperquality,paperthickness,papergraindirection,cutting

precision, print condition, and processing speed etc., is necessary.

Align the stacker roller position to "6."

Usethe"stackerrollerpositioningtable"asreferencetosetthestackerrollerposition.

Chapter 2 “3-4. Aligning stacker roller position” (p.23)

2-4. Performing folding operation

Chapter 2 “3-7. Setting counter” (p.25)

“3-8. Performing folding operation” (p.26)
