23
Chapter 2 Basic Operation
Copyright © 2018 Duplo Corporation All Rights Reserved
3-4. Aligning stacker roller position
DF-850
Move the stacker roller in line with the
table.
The position of the stacker roller depends on
thepapersizetobeusedanditsfoldingform.
Refer to the table for the position check.
For EU
For NA
• Thistableisthemeasureforuse.
• WhenstackingA4andB5withlongedgefeed,considerthepapersizetobeA5andA6,
respectively.Forexample,whensinglefoldingA4withlongedgefeed,setthepositionofthe
stackerrollerto[5].(EU)
• Whenstackinglettersizepaperwithlongedgefeed,considerthepapersizetobe[ST/IN],
respectively.Forexample,whensinglefoldinglettersizepaperwithlongedgefeed,setthe
positionofthestackerrollerto[5].(NA)
DF-870
Ifpaperisnotsmoothlyejectedduringtestfolding,ortheejectedpaperispoorlyarrayed,changethe
stacker roller position.
SingleFold
P Length 420.0
S-Roller 2
P Length 420.0
S-Roller 2
P Length 420.0
S-Roller 1
S-Roller
S-Roller
< 2 >
1 >
A3 +Count:0000
IfusinggatefoldingofA3orotherlargepaperinhightemperatureandhighhumidity,thepapermay
become poorly arrayed. In this case, change the stacker roller position from [1] to [2].
