Duplo DF-850 - 6-1. Correcting folding misalignment along vertical length of paper

44
Chapter3AdvancedOperation
Copyright © 2018 Duplo Corporation All Rights Reserved
For NA
For EU
3) Whilepullingontheroughadjustmentknob
of the folding plate 2, move to the highest
point.
4) Rotatetheneadjustmentknobforthe
foldingplate2totheleft,andadjustsothat
the stopper is completely and lightly bumped.
DF-870
SingleFold
LP +Count:0000
1) Pressthe key,andsetthepapersizeto
[LP].
LP +Count:0000
SingleFold
2) Pressthe key, and set the folding mode to
[SingleFold].
3) Inputthepaperlength"150."
For the paper length calculation method, see
the“Roughadjustmentknobsetposition
table”(p.36).
P Length
420.0 mm
P Length
120.0 mm
P Length
150.0 mm
SingleFold
LP +Count:0000
P Length 420.0
S-Roller 6
P Length
420.0 mm
P Length
120.0 mm
P Length 150.0
S-Roller 6
