Setup
100
Operating Instructions 967 - 02.0 - 1
1/2016
7.9.1
Connecting the sewing lamp
Fig. 54: Connecting the sewing lamp (1)
To connect the sewing lamp:
1.
Remove the control (2)
if the control (2) has a
lready been
assembled.
2.
Open the hou
sing cover (1).
3.
Connect the cable (3) to contacts
3
and
4
on the terminal strip (4).
4.
Close the hous
ing cover (1).
(1)
- Housin
g cover
(2)
- Control
(3)
- Cable
(4)
- Terminal
strip
③
④
①
②
101
103
