Operation
44 Operating Instructions 967 - 02.0 - 11/2016
Information
The control will stop the machine at 2 preset needle positions.
The standard positions are:
• the needle remains in the sewing material at a stop in the
seam
• the needle is outside of the sewing material (pedal at
position -2) after the thread has been cut
4.8.3 Positioning the needle automatically
The electronic handwheel (1) can be used to set a point position.
This function makes it possible to set the needle to any freely
defined position.
A press on the electronic handwheel (1) will trigger a move to the
defined position.
Fig. 23: Positioning the needle automatically
To position the needle automatically:
1. Switch on the machine.
The electronic handwheel (1) is inactive.
(1) - Electronic handwheel
(2) - Pedal
(3) - Handwheel
