Maintenance
Operating Instructions 967 - 02.0 - 11/2016 85
5. Tighten the drain screw (3).
6. Connect the machine to the compressed air supply.
6.3.3 Cleaning the filter element
Fig. 44: Cleaning the filter element
To clean the filter element:
1. Disconnect the machine from the compressed air supply.
2. Drain the water condensation ( p. 84).
3. Loosen the water separator (2).
4. Loosen the filter element (1).
NOTICE
Damage to the paintwork from solvent-based cleaners!
Solvent-based cleaners damage the filter.
Use only solvent-free substances for washing out the filter
tray.
(1) - Filter element
(2) - Water separator
(3) - Drain screw
