Operation
54 Operating Instructions 967 - 02.0 - 11/2016
4.10.1 Setting the stitch length
Depending on the equipment, the machine has 1 or 2 adjusting
wheels for stitch length.
The stitch length can be adjusted continuously between 0 and
15 mm.
Fig. 29: Setting the stitch length
To set the stitch length:
1. Turn the desired adjusting wheel.
• Reduce stitch length: turn clockwise
• Increase stitch length: turn counterclockwise
(1) - Adjusting wheel for the longer
Stitch length
(2) - Adjusting wheel for the shorter
Stitch length
