Technical data
Operating Instructions 967 - 02.0 - 11/2016 123
11 Technical data
Data and characteristic values
Technical data Unit
967-100180
967-100382
967-111382-100
Type of stitches Lockstitch 301
Hook type Barrel shuttle hook
Number of needles 1
Needle system 794/7x23/328/1000H
Needle strength [Nm] 120-280
Thread strength [Nm] 40/3 - 5/3
Stitch length [mm] 15/15
Speed maximum
[min
-1
]
1000 1250 1000
Speed on delivery
[min
-1
]
1000 1000 700
Mains voltage [V] 230
Mains frequency [Hz] 50/60
Operating pressure [bar] 6
Length [mm] 700 700 1300
Width [mm] 250 250 290
Height [mm] 420 420 420
Weight [kg] Standard arm: 90
Long arm: 145
