Operation
66 Operating Instructions 967 - 02.0 - 11/2016
4.14 Thread clamp (optional)
The thread clamp is used to pull the sewn threads under the sewing
material at each beginning of the seam. The thread clamp clamps
the thread during the first stitch, while the sewing feet are raised
briefly.
Fig. 36: Thread clamp
To activate or deactivate the thread clamp:
1. Press the button for the thread clamp on the OP1000 (2).
When the thread clamp is activated, the LED on the OP1000
will be on.
When the thread clamp is deactivated, the LED on the OP1000
will be off.
(1) - Thread clamp (2) - OP1000
