Operation
48 Operating Instructions 967 - 02.0 - 11/2016
1. Press the pedal to position -1.
The sewing feet are lifted to the maximum, and the lock is
canceled.
4.9.3 Setting the sewing foot pressure
Proper setting
The sewing material does not slip and is correctly transported.
Disturbance
Excessively high sewing foot pressure:
• Tearing of the sewing material
• Sewing feet impressions on the sewing material
Excessively low sewing foot pressure:
• Slipping of the sewing material
Fig. 26: Setting the sewing foot pressure
(1) - Adjusting wheel
(2) - Counternut
(3) - Auxiliary spring
