Operation
Operating Instructions 967 - 02.0 - 11/2016 47
4.9.2 Lifting the sewing feet manually
There is a lever on top of the machine for holding the sewing feet
at top dead center.
Fig. 25: Lifting the sewing feet manually
Lifting the sewing feet
To lift the sewing feet manually:
1. Turn the lever to position 1 (2).
The sewing feet are raised by 14 mm.
2. Turn the lever to position 2 (3).
The sewing feet are raised by 20 mm.
Lowering the sewing feet
To lower the sewing feet:
1. Turn the lever to position 0 (1).
The lock is canceled.
OR
(1) - Lever in position 0
(2) - Lever in position 1
(3) - Lever in position 2
