Operation
Operating Instructions 967 - 02.0 - 11/2016 63
To transfer a button function to the favorite button:
1. Turn all screws (3) to their initial position so that the slots are
horizontal.
2. Turn the screw under the desired button 90° so that the slot
is vertical.
4.12 Thread cutting and seam securement
Machines fitted with the Classic equipment come standard with a
thread cutter. The thread cutter is located under the throat plate
and cuts the threads at the seam end. The hook thread is clamped
by a spring to ensure that the next seam is sewn on securely.
4.12.1 Cutting off the thread
Fig. 35: Cutting off the thread
(1) - Length of thread end in needle
(2) - Pedal
(3) - Position -2: Cutting and
Bar tacking
(4) - Control panel OP1000
(5) - Pre-tensioner
