DURKOPP ADLER 967 - Activating Quick Stroke Adjustment Via the Knee Button

Operation
52 Operating Instructions 967 - 02.0 - 11/2016
4.9.5 Activating quick stroke adjustment via the knee
button
On machines where quick stroke adjustment is activated via a
knee button, the elevated sewing foot stroke is switched on and
off using the knee button. The toggle switch on the rear side of
the knee button determines whether the elevated sewing foot
stroke is switched on permanently or only while the knee button
is pressed.
Fig. 28: Setting quick stroke adjustment via the knee button
Permanent conversion to quick stroke adjustment
To permanently convert to quick stroke adjustment:
1. Set the toggle switch (2) to the upper position.
• To activate elevated sewing foot stroke: Push the knee
button (1) to the right
• To switch elevated sewing foot stroke off: Push the knee
button (1) to the right again
(1) - Knee button (2) - Toggle switch
①
②
