Operation
Operating Instructions 967 - 02.0 - 11/2016 43
4.8.2 Positioning the needle semi-automatically
Fig. 22: Positioning the needle semi-automatically
Information
The needle can only be positioned semi-automatically by turning
the electronic handwheel (1).
The electronic handwheel (1) is activated by briefly pressing the
pedal (2) or by turning the handwheel (3).
The movement will not be detected if the electronic handwheel (1)
is turned too fast or too slowly.
To position the needle semi-automatically:
1. Switch on the machine.
The electronic handwheel (1) is inactive.
2. Press the pedal (2) or turn the handwheel (3).
The electronic handwheel (1) is active.
3. Turn the electronic handwheel (1) until the needle has reached
the desired position.
(1) - Electronic handwheel
(2) - Pedal
(3) - Handwheel
