Setup
94
Operating Instructions 967 - 02.0 - 1
1/2016
7.6
Setting the pedal
Fig. 50: Setting the pedal
To set the pedal:
1.
Set the pedal (2)
so that it is
ce
ntered relative to the axis of
the needle.
2.
Set the connecting piece of the pull rod (1) so that the pedal
(2)
has the desired angular position.
(1)
- Connec
ting piec
e on the
Pull rod
(2)
- Pedal
②
①
95
