Machine description
16 Operating Instructions 967 - 02.0 - 11/2016
Fig. 2: Components of the machine (2), machines with long arm
(1) - Hand lever
(2) - Adjusting wheel for elevated
sewing foot stroke*
(3) - Adjusting wheel for normal
sewing foot stroke
(4) - Adjusting wheel for sewing
foot pressure
(5) - Winder
(6) - Thread tensioner
(7) - Thread clamp**
(8) - Sewing feet with needle
(9) - Cover
(10)- Buttons on the machine arm
(11)- Electronic handwheel
(12)- Control panel OP1000
(13)- Stitch adjustment lever
(14)- Additional handwheel
(15)- Adjusting wheel for the shorter
stitch length*
(16)- Adjusting wheel for the longer
stitch length*
(17)- Oil level indicator
(18)- Handwheel
(19)- Reel stand
