Operatio
n
Operating Instructions 967 - 02.0 - 11/2016
33
2.
Switch off the machine.
3.
Remove the cover
(2).
Fig. 13: Changing the bobbin (2)
4.
Open the latch (4).
The bobbin case (5) opens, and the bobbi
n is pushed out.
Fig. 14: Changing the bobbin (3)
(4)
- Latc
h
(5)
- Bobb
in case
④
⑤
(5)
- Bobbin
case
(6)
- Slot
(7)
- Thre
ad tension spr
ing
(8)
- Slot
(9)
- Bobbin
(10)
- Driver hole
⑤
⑥
⑦
⑧
⑨
⑩
34
36
