Durst Omega 2 - C Description; Printer

C Des crip tion Omega 2
C Description
1Printer
Task The printer prints plate m edia and roll media.
Components The printer consists of the following components:
1UVlamphead
2 Print carriage
3 Loading aid
4 Loading unit
5Platemedium
6 Sliding door
7 Ink supply unit
8 Take-up roll
9 Unloading unit
10 Roll medium
1
3
1
7
2
3
4
9
6
6
5
10
8
Fig. 6 Components of the printer (top: Loading side – here, for printing
a plate medium; below: Unloading side – here, for printing a
roll medium)
A conveyor belt transports the medium from the loading unit (4) through the
printer to the unloading unit (9).
