Omega 2 C Description
Components The cleaning system is comprised of a spitting tray and the cleaning access
point.
1 Light traps
2 Cleaning access point
1
2
Fig. 8 Cleaning system
Function Whe n the spitting process is initiated, ink is pressed through the print heads
and collected in the spitting tray (1).
The cleaning access point (2) allows manual cleaning of the print heads
from below.
2Workflow
Fig. 9 Workflow
