Omega 2 F Softw are
Delete The selected media channel is deleted with the Delete button.
3.2 C reating and editing media channels
3.2.1 O pen ing Media dialog w indow
Click Media.
3.2.2 Creating new media chann el
✔ The Media dialog window is open
1. To create a media channel with completely new data, carry out the
following steps:
– Click New.
– Enter all desired values.
2. To create a new media channel based on an existing media channel,
carry out the following steps:
– Select desired existing media channel in the navigation win
dow.
– Click Copy.
– Modify desired parameters.
– Rename media channel if necessary.
3. Click Save.
3.2.3 Deleting media channel
✔ The Media dialog window is open
1. Select desired media channel in the navigation window.
2. Click Delete.
3.2.4 Determining encoder offset
Theencodertestimageshouldbewelldefined, and the lines under "Encoder
Test" should be as thin as possible.
✔ The Pass overlapping fu
nction on the Print options sub-tab is
deactivated
1. Print the Durst test image EncoderTestImage+ in hotfolder 1.
2. If stripes are visible in the blue area of the test image, proceed as follows:
– White stripes: Reduce encoder offset (negative values are also
possible)
– Black stripes: Increase encoder offset
4 Operating p
rinter functions
4.1 B asic functions
You operate the following basic functions on the Printer tab:
