E Operation Omega 2
EOperation
1 An overview of daily tasks
1.1 Performing daily tasks
Preparing printer
1. Switch on printer.
2. Start up workstation if not already done.
3. Change refill tank for ink, if applicable.
4. Initia lize printer.
The multiple spitting process is started automatically.
5. After the multiple spitting process is completed, carry out morning
cleaning (→ Page 68 / Service).
6. Load medium.
7. Set the suction area.
Printing
8. If necessary, print the encoder test image and correct the encoder offset.
9. Prepare images on external RIP server and send them to the printer.
10. Select o r check print options at the workstation .
11. Move images to the queue.
12. Print me dia.
Finishing w ork
For economical work, we recommend not shutting down the workstation
when switching off the printer.
This enables y ou to prepare data and transfer it from the RIP server to
the workstation even if the printer is switched off.
13. Start the daily switch-off procedure.
14. Switch off printer with the main switch.
2 Workstation
2.1 Connection of external devices
2.1.1 Connecting a USB stick/an external USB hard disk
Data transfer from an external USB hard disk, for example, only makes
sense via the connected RIP server since the image data to be printed
must be in the 1-bit format.
Connection of an incompatible device to the workstation!
Damage to the workstat ion
Connect only SELV-compatible devices to the workstation.
28 / 9 1 2004 – 2014 © Durst Ph ototechnik AG – www.d urst-online .com , Omega 2, Issued 0 7/20 14
